  • Double piston continuous hydraulic screen changer
Double piston continuous hydraulic screen changer

Double piston continuous hydraulic screen changer

  • bear high pressure 50Mpa
  • continuous production when changing screen
  • Product description: Double piston continuous hydraulic screen changer is an screen changer with double piston and two working stations, can realize continuous production when changing screen.
  • INQUIRY

Double piston continuous hydraulic screen changer

Double piston continuous hydraulic screen changer is an screen changer with double piston and two working stations, can realize continuous production when changing screen.


Features

1. designed with exhaust system, remove the gas contained in material to improve product quality.

2. its double channel design increases the filtration area and meets the production requirements of higher output and high quality.

3. it has the function of fillings, exhaust and sewage discharge to ensure the continuity of the products in the process of changing the net.

4. can be customized kinds of size according to customers requirement

5. equipped with safety shield


Application

Chemical fiber, blowing film, flat film, cast film, pipe, plate, wire, fiber, granulation, recovery granulation and so on.

Technical parameter


Type

Screen size

Heat power

(kw)

Capacity

(kg/h)

Dia(mm)

Area (cm2 )

GY-DC-2-80

60

28*2

3-4.2

180

GY-DC-2-100

80

50*2

4.8-6.6

280

GY-DC-2-120

100

78*2

5.4-7.2

380

GY-DC-2-145

125

123*2

8.4-10.8

700

GY-DC-2-170

150

176*2

9.6-13.2

1100

GY-DC-2-195

175

240*2

15-21

1500

GY-DC-2-220

200

314*2

23-28

1900

GY-DC-2-250

230

415*2

30-38.4

2600
